Complete Exhaust Guide for Toyota Landcruiser 76 Series
Share
The Toyota Landcruiser 76 Series Wagon is a bit of a legend in the Australian 4x4 world. It's the go to choice for people who want serious off-road capability without the compromises that come with a more road focused SUV. Whether you're crossing the Simpson Desert, running a remote station or just doing long highway miles with a heavy trailer the 76 Series is built for it.
But like most factory vehicles the exhaust system is one area where Toyota played it safe. Upgrading to a quality aftermarket exhaust is one of the most effective modifications you can make and this guide covers everything you need to know to make the right call for your 76 Series.
Why Upgrade the Exhaust on Your 76 Series Landcruiser?
The factory exhaust on the 76 Series does the job but it's not optimised for performance. Here's what a quality aftermarket system delivers:
- Reduced backpressure — lets the engine breathe more freely under load
- Improved torque and throttle response — especially noticeable when towing or loaded up
- Better fuel economy — less restriction means the engine works less hard at highway speeds
- A deeper, more satisfying exhaust note — without being antisocial
- Superior durability — quality stainless steel outlasts the factory mild steel system especially in coastal or outback conditions
For a vehicle that's regularly pushed hard towing, off road, long distance touring an exhaust upgrade is one of the best bang for buck modifications available.
Understanding the 76 Series Engine
The 76 Series has been powered by the 4.5L V8 twin-turbo diesel (1VD-FTV) since 2007. There are two key variants to be aware of when choosing an exhaust:
- 2007–2016 (Pre-DPF): These models do not have a factory Diesel Particulate Filter. A full turbo-back exhaust system is the most effective upgrade.
- 2016-On (with DPF): These models came with a factory DPF fitted to meet emissions standards. Removing or bypassing the DPF is illegal on Australian roads so the exhaust options are different for this generation.
Knowing your build year is the single most important factor when choosing the right exhaust system.
76 Series Exhaust Systems — At a Glance
| Exhaust System | Engine Fit | Tube Size | Best For | Key Benefit |
|---|---|---|---|---|
| DPF-Back Exhaust | 4.5L V8 1VD-FTV (2016-On, with DPF) | 3.5" | Late model 76 Series owners wanting a practical upgrade | Improved flow, better sound and throttle response |
| Turbo-Back Exhaust (with high-flow cat) | 4.5L V8 1VD-FTV (2016-On, with DPF) | 3.5" | 2016-on owners running a tune who want the most complete system | Maximum flow from turbo outlet to tailpipe pairs perfectly with a diesel tune |
| Turbo-Back Exhaust Stainless Steel | 4.5L V8 1VD-FTV (2007–2016, pre-DPF) | 3.5" | Pre-2016 76 Series owners wanting the definitive exhaust upgrade | Full turbo to tailpipe upgrade in premium stainless the go to for pre-DPF builds |
What Exhausts systems are available for the 76 Series
At Outback Exhausts we manufacture a complete range of exhaust systems specifically engineered for the VDJ76 Wagon. Here's what's available and what each system does.
DPF-Back Exhaust — VDJ76 4.5L V8 Wagon (2016-On)
If your 76 Series was built from 2016 onwards it left the factory with a Diesel Particulate Filter. A DPF-back exhaust replaces everything from the DPF outlet back to the tailpipe. It's the legal, practical upgrade for late model 76 Series owners.
You get improved exhaust flow, a better sound, and a noticeable improvement in throttle response, all while staying fully ADR compliant. For most 2016-on owners, this is the right starting point.
DPF Back Exhaust — Toyota Landcruiser 76 Series VDJ76 4.5L V8 Wagon (2016-On)
Turbo-Back Exhaust — VDJ76 4.5L V8 Wagon (2016-On)
For 2016-on owners who want the most complete exhaust upgrade possible our turbo-back system replaces everything from the turbocharger outlet all the way to the tailpipe including a high flow catalytic converter. This is the full system for maximum flow and performance and pairs perfectly with a diesel tune. Please note that turbo-back systems involving DPF removal are intended for off-road use only, including applications on private property, farms, and mining sites.
Turbo Back Exhaust — Toyota Landcruiser 76 Series VDJ76 4.5L V8 Wagon (2016-On)
Turbo-Back Exhaust — VDJ76 4.5L V8 Stainless Steel (2007–2016)
The pre-DPF 76 Series is a favourite among serious tourers and off road enthusiasts. Without the DPF complication a full turbo-back system is the most effective single exhaust upgrade you can make. Our stainless steel system is engineered specifically for the VDJ76 and built to handle whatever Australia throws at it.
Turbo Back Exhaust — Toyota Landcruiser 76 Series VDJ76 4.5L V8 Stainless Steel (2007–2016)
Browse the Full 76 Series Exhaust Range
Not sure which system suits your build? Browse our complete collections below:
DPF-Back vs. Turbo-Back: Which One Do I Need?
This is the question we get asked most often, and the answer is straightforward once you know your build year.
- 2016-on VDJ76 (with DPF): A DPF-back exhaust is the legal, practical choice for most owners. If you're running a tune and want the full system go turbo-back with a high-flow cat. Please note that turbo-back systems involving DPF removal are intended for off-road use only, including applications on private property, farms and mining sites.
- 2007–2016 VDJ76 (pre-DPF): A turbo-back system gives you the full benefit of improved flow from the turbo outlet all the way back this is the go-to upgrade for this generation.
If you're still not sure, get in touch — we're happy to help you find the right fit for your setup and budget.
What Size Exhaust Should I Run on My 76 Series?
For the 4.5L V8 1VD-FTV, a 3.5-inch (89mm) exhaust system is the recommended size. It's a meaningful step up from the factory system and provides the right balance of flow and exhaust velocity across the RPM range.
Going larger than 3.5 inches on a stock or mildly tuned engine can actually reduce low end torque by dropping exhaust velocity too much. Our systems are engineered to the correct diameter for each application — you don't need to guess.
Frequently Asked Questions
Do I need a tune after fitting an exhaust on my 76 Series?
You don't need a tune to run our exhaust systems they're designed to work on a stock engine and you'll notice an improvement straight away. That said pairing an exhaust upgrade with a quality diesel tune will give you the best results in terms of power, torque and fuel economy. The two work very well together.
How long does installation take?
A typical exhaust installation on a 76 Series takes around 2–4 hours at a workshop. Our systems are direct-fit so there's no cutting or custom fabrication required just bolt-on and go.
Are your exhausts made in Australia?
Yes. Outback Exhausts are proudly Australian-made. We manufacture our systems locally using premium materials and every system is built to suit Australian conditions. When you buy from us you're supporting local manufacturing.
Can I fit the exhaust myself?
If you're mechanically confident and have access to a vehicle lift or solid ramps a DIY install is achievable. Most of our customers have the system fitted by a local exhaust shop or 4x4 workshop it's a straightforward job for anyone who knows their way around a vehicle.
Do you ship Australia-wide?
Yes we ship to all states and territories across Australia. Most metro areas receive their order within 2–5 business days.
We also ship to international destinations. If you're ordering from overseas, please call or get in touch with us to confirm shipping options and freight costs.
What's the difference between the 76 Series and 78 Series exhaust systems?
The 76 Series (Wagon) and 78 Series (Troop Carrier) share the same 4.5L V8 engine but have different body configurations and exhaust routing. The systems are not interchangeable make sure you select the exhaust that's specifically engineered for your model.
Ready to Upgrade Your 76 Series Exhaust?
The 76 Series Wagon is one of the most capable 4x4s on the planet it deserves an exhaust system that matches. Whether you're running a late-model VDJ76 with a DPF or a pre-2016 model, we've got a system built specifically for your vehicle.
Browse the full range or get in touch if you need help choosing the right system for your setup.
Disclaimer: The turbo-back exhaust system for 2016-on 4.5L V8 1VD-FTV models is intended strictly for off-road racing, ADF, mining vehicles, overseas models exempt from Australian Design Rules (ADR) or vehicles with valid Primary Producer exemptions. Installing this product on a 2016-on model renders the vehicle non-compliant with ADR standards for road use. It is the owner's responsibility to verify regulatory compliance before purchasing.
